SS49E Linear Hall Effect Sensor Module

Analogy Hall Magnetic Sensors are 3144 Series Hall effect Switch ICs that employ technology to create magnetic semiconductor integrated circuits. These circuits are determined by the voltage regulator, Hall voltage generator, differential amplifier, Schmidt trigger, temperature compensation circuit, and the collector electrode open-circuit output stage, which includes the magnetic sensing circuit and takes the magnetic flux density as an input and output. A straightforward circuit creates a magnetic flash using a built-in 13 LED, an analogue magnetic sensor module, and a digital interface.

 Specifications

• Operating Voltage: 5 V
• Type: Magnetic Sensor Module
• Mainly Compatible with: Ardunio
• Dimension(mm): 30 x 15 x 6
• Weight:1g
