Product details
The charger operates with a charging voltage of DC 5V and consumes a charging current of 2.5A. It features overcharge detection at 4.25 ± 0.025V and overcharge release at 4.19V ± 0.050V. The charger is equipped with an LED indicator that shows the charging progress. Additionally, this charger can be transformed into an 11.1V battery module, which offers two types of outputs one provides direct output without short circuit protection (Output A), and the other includes short circuit protection (Output B). It also features an onboard output power LED and an output power status LED for easy monitoring, as well as an onboard power switch for turning the device on and off. For connectivity, two output pins are available – one is a two-pin terminal connector, and the other is a header pin. This charger is suitable for use in robotics, IoT, and Arduino projects.
Specifications
- Charging voltage: DC 5V
- Charging Current consumption: 5A
- Overcharge detection voltage: 4.25 ± 0.025V
- Overcharge release voltage: 4.19V±0.050V
- Over discharge detection voltage range: 2.80 ± 0.10V
- Over discharge release voltage: 3.0±0.10V
- The Charger is equipped with an LED indicator that displays the charging progress
- This charger can be transformed into a 1V battery module
- The battery module has two types of outputs: one provides direct output without short circuit protection, while the other includes short circuit protection
- Output A is without short circuit protection, while Output B includes short circuit protection
- An onboard output power LED and an output power status LED are available.
- An onboard power switch is available for turning the device on and off
- Two output pins are available: one is a two-pin terminal connector, and the other is a header pin.
- Charger Size:90.8×17.3×92.7mm
- Charger Weight: 78g (Without Battery).
