Product details
The ultrasonic sensors used in automobiles and this one are extremely similar. This waterproof ultrasonic obstacle sensor outperforms traditional sensors in terms of construction. The control board and the transducer, which serves as the sensing component, are packaged separately.
The module is able to provide details on objects between a range of 250 mm and 4500 mm away. The ability to place the sensing element remotely from the entire control circuitry is a major benefit of employing this waterproof ultrasonic obstacle sensor.
An industrial-grade sensor to measure distance is the ultrasonic distance sensor. It has the same interface as another inexpensive ultrasonic sensor, but it performs better, can withstand more extreme conditions, and is waterproof as well. It is simple to interface with Arduino, and there are projects and sample programmes available.
Although there are many ultrasonic distance sensors available, they occasionally need to operate in risky situations. This criteria is met by the waterproof ultrasonic obstacle sensor. It performs well and uses nearly the same amount of power as an HC-SR04 module.
It is fairly simple to use; a control port with a high-level output threshold of 10 US can wait for output at that threshold at the receiving port. When this port is low, an output can read the timer value and drive the timer; this allows for the position of the time to be determined via distance measurement. Cycle tests that can determine the value of your mobile device frequently.
Specifications
- Operating Voltage: 5 V
- Operating Current:30mA
- Sonar Sensing Range: 25-450 cm
- Sensing Range: 450 cm
- Resolution: 0.5 cm
- Detecting Angle: < 70°
- Operating Temperature: -10 ~ +70
- Cable Length: 2.5 meter
- Frequency: 40 KHz
