Product details
This custom designed module for the DS1307 Real Time Clock. The module comes fully assembled and pre-programmed with the current time. The included Lithium coin cell battery (CR2032/ 240mAh) will run the module for a minimum of 5 years .without external 5V power. The DS1307 RTC is accessed via the I2C protocol. We have written a test-bed to program the modules. This test-bed code should give you some insight on how to interface the module to any microcontroller using our example software I2C and BCD routines.
- Two wire I2C interface
- Hour : Minutes : Seconds AM/PM
- Day Month, Date – Year
- Leap year compensation
- Accurate calendar up to the year 2100
- Battery backup included
- 1Hz output pin
- 56 Bytes of Non-volatile memory available to the user
- PCB Dimensions(LxWxH in mm): 39.6×1.5×63.1mm
- Weight: 16g (With battery).
